File > Save As > Save as type > VDAFS > Options > VDA

Setting

Get/Set Methods

Return Value
or
<Value>

Comment

Output coordinate system

IModelDocExtension::GetUserPreferenceString(swUserPreferenceString_e.swFileSaveAsCoordinateSystem, swUserPreferenceOption_e.swDetailingNoOptionSpecified)

IModelDocExtension::SetUserPreferenceString(swUserPreferenceString_e.swFileSaveAsCoordinateSystem, swUserPreferenceOption_e.swDetailingNoOptionSpecified, <Value>)

String value

Contains the name of the transform coordinate system; an empty string signifies that the default coordinate system that does not require a transform; coordinate settings are not saved with the document; they must be selected at export time

Search 'File> Save As> Save as type > VDAFS > Options >: VDA' in the SOLIDWORKS Knowledge Base.
