Shared Sketch

You can use the same sketch to create different features.

To create different features with the same sketch:

1. Create a sketch.

2. Create a feature from the sketch.

3. In the FeatureManager design tree, select the same sketch used to create the first feature.

4. Create a second feature from the sketch.

You can add additional sketches as required to create the features. For example, if one feature is an extrude and the other feature is a revolve, use the same sketch for both features, but add a centerline to create the revolve.

In the FeatureManager design tree, a sketch that is shared by multiple features is identified by .
