Inserting a Predefined View into a Drawing

To insert a predefined view into a drawing:

  1. In a drawing document, click Predefined View tool_Predefined_View_Drawing.gif (Drawing toolbar), or click Insert > Drawing View > Predefined.
  2. Click in the graphics area to place the view.
  3. Set options in the PropertyManager.
  4. Click PM_OK.gif.
You can populate the view as you insert it, or you can populate it later.
