Adding Projected Views to Predefined Views

You can add projected views to a predefined view. For example, if you insert a front view, you can project top and right views to create a predefined Standard 3 View. Projected views are automatically oriented and aligned to the original view. The projected views act as predefined views.

You can copy and paste predefined views.
