Creating Custom Symbols

You can create custom symbols to use in most annotations, tables, and dimensions in a SOLIDWORKS drawing.

Before you begin, you should back up the original symbol file, gtol.sym, located in drive letter:\lang\english. Browse to the file, make a copy of the file, and save it in a different directory so you can retrieve it if necessary.
