Entire model |
Inserts model items for the whole model.
![model_items_entire_model.gif](dne1450447336199.image)
|
Selected feature |
Inserts model items for the feature you select in the graphics area.
![model_items_selected_feature.gif](ilf1450447336743.image)
|
Selected component (assembly drawings only) |
Inserts model items for the component you select in the graphics area.
![model_items_selected_component.gif](boz1450447338177.image)
|
Only assembly (assembly drawings only) |
Inserts model items for assembly features only. For example, you can insert dimensions that reside exclusively in the assembly, such as Distance and Angle mates.
![model_items_only_assy.gif](owk1450447338684.image)
|
Import items into all views |
Inserts model items into all drawing views on the sheet. When cleared, you must select the drawing views to which you want to import model items.
|
Destination view(s) |
Lists the drawing views where the model items will be inserted. This option is available when Import items into all views is cleared.
|
