BOM View

BOM view lists the activated and named BOMs in the current folder and lets you view and modify their details.

1 Navigation pane Lets you browse vaults and folders.
2 Windows File Explorer ribbon control Contains commands that apply to the selected file or folder.
Only View commands and few other commands of the ribbon control are supported.

When you are logged in to a vault, the Help button on the Windows File Explorer ribbon control opens the SOLIDWORKS PDM File Explorer help.
3 SOLIDWORKS PDM menu bar Contains menus of commands that can be performed for the selected file or folder.
4 BOM lists Lists the named and activated BOMs in the current folder.
5 BOM contents Displays the details of the BOM, which depend on the type of BOM you are viewing.
