Copying Cut List Properties to Cut List Items (2024 SP1)

You can create cut list properties and copy them to other cut list items.

To copy cut list properties to cut list items:
  1. Open a part.
  2. In the FeatureManager design tree, right-click a cut list item and select Properties.
  3. In the Cut-List Properties dialog box, on the Cut List Summary tab, create a cut list property.
  4. Select the property, click Copy to, and select one of the following:

    All cut list items

    Copies the selected property to all cut list items.

    Specific cut list items

    Copies the selected property to specific cut list items.
Copy to is available for user-defined properties only for files that use a new architecture.
Copy to copies the property of a cut list item to:
  • All or specific cut list items that are available in the active configuration.
  • The same cut list items that are available in the remaining configurations.
