Using Custom Environments

You can add image files to create custom floor and sky environments in VR.

Requirements include:
  • Floor. Must be .png or .jpg files.
  • Sky. Equirectangular .png or .jpg files. Skies must be equirectangular. Images must have an aspect ratio of 2:1. Cube maps are not supported.
Floor Sky

To use custom environments:

  1. Click VR Options (if you have a VR model open) or Tools > VR Options.
  2. In the VR Engine Settings dialog box, under Additional Sky Folder or Additional Floor Folder, browse to a folder that includes the image files and click OK.
  3. In the Environment pane, set the Sky or Floor.
