Mirror Drawing Views

You can display model, relative to model, and predefined drawing views as mirror views without creating the mirror components. Projected and other derived views use the mirror state from their parent view.

To mirror drawing views:

1. In a drawing, select a model, relative to model, or predefined drawing view.
2. In the PropertyManager, under Mirror, select Mirror view.
3. Under Mirror view, select Horizontal or Vertical.
4. Click .
