 | Compute | Performs the selected test. |
 | Save Results | Saves results in XML, HTML, Excel, or CSV format. |
 | Load Results | Loads a previously saved file of clearance results to avoid recalculating. |
 | View/Hide Result | Displays or hides results. |
 | Show Selected Result Only with Ghost | Ghosts the selected results. |
 | Build Collaboration | Creates intersection-line collaborative actors for the selected results. See also
Multi-line building.
|
 | Clear All | Clears the clearance checking session. |
| Multi-line building | Creates an intersection-line collaborative actor for each intersection between two actors. To create one intersection line with all intersections between actors, clear this option.
|
| Result Columns | Displays the contacts and intersections. Click a result to see the actors in the scene. Right-click a result and click
Fill data to add comments or select a
Status (
Undefined,
Relevant, or
Irrelevant). |
