You can
use the AM_WELDINGSYMBOL command to add welding
symbols
to
drawings.
The welding symbols
ensure clear communication of welding specifications and
adherence
to industry standards. They enhance the accuracy and quality of technical
documentation.
The AMWELDSYM
command
offers multiple options for flexible and precise placement of welding symbols:
- Supports
a
range of standard welding symbols that represent various weld types.
- Lets
you
customize
symbol type, size, angle, and placement to
meet
project requirements.
- Provides options for adding symbols like all around, field weld, and
staggered fillet welds at the arrow's junction with the reference line.
- Lets
you
include multiple reference lines and arrows to indicate weld sequences and identical
weld locations.
- Attaches symbols to objects and ensures they move with the object
when repositioned.
- Places symbols as stand-alone annotations.
- Includes
ways
to
add
details for specific welding processes.
