Full section |
The cutting plane passes through
the entire length of the entity. |
Aligned section |
Two nonparallel cutting planes
pass through the entity. Use these sections on cylindrical
entities. |
Half section |
The cutting plane passes through a
portion of the entity to section. |
Offset section |
The cutting plane bends to pass
through the features of the entity. Use these sections on entities
that are not in a straight line. |
